JOLTING TABLE (C125)

Category: Cement

Product Code: C125

Category: CEMENT

Sub-Category: SPECIMEN PREPARATION



  • The Jolting Table is specifically designed for compacting cement mortar prisms measuring 40 × 40 × 160 mm, ensuring uniform density and consistency for subsequent strength testing.
  • The apparatus features a mould table mounted above a cam that rotates at 60 revolutions per minute, delivering a consistent drop height of 15 mm to compact the mortar effectively.
  • Equipped with a digital cycle counter, the Jolting Table allows precise control over the number of jolts, enhancing repeatability and compliance with testing standards.
  • The motor and gearbox assembly are enclosed within a protective housing, eliminating exposure to moving parts and enhancing operator safety during operation.
  • A noise-reduction cabinet (optional accessory) is available to minimize operational noise, providing a safer and more comfortable working environment.


STANDARDS

EN 196-1 • ISO 679 • EN 413-2 • EN 459-2 • EN 13454-2 • BS 3892-1 • BS 4551-1 • EN 1015-10 • EN 1015-11 • EN 1744-1

TECHNICAL SPECIFICATIONS

  • Specimen Size: 40 × 40 × 160 mm
  • Cam Rotation Speed: 60 rpm
  • Table Drop Height: 15 mm
  • Cycle Counter: Digital
  • Power Supply: 220–240 V / 50 Hz
  • Optional Power Supply: 110 V / 60 Hz
  • Motor Power: 250 W
  • Dimensions: 1000 × 380 × 420 mm
  • Weight: Approximately 60 kg

ORDERING INFORMATION

Item Code
JOLTING TABLE C125X00ET
JOLTING TABLE [60 Hz] C125X00EK
SAFETY CABINET for JOLTING TABLE C125P001H
